Main Lift Assembly

Позиция	Артикул	Наименование
1	088001585	EDGE Rear Panel Asm
2	088001565	Chain Drive Assembly, Odd
3	088001566	Chain Drive Assembly, Even
4	088001507BX	EDGE Carrier Rail Boxed
5	088001518	Carrier Rail Spring
6	088001589	Front Panel Asm Odd
7	088001586	EDGE Front Panel Asm Even
8	809849605BG	Cap Screw, Hex Head, 1/4-20 X 3.75 (Bag of 10)
9	000026865BG	Flat Washer 0.25 X 0.41, Cadmium (Bag of 10)
10	088001542	Spacer, 3.1" Long
11	088001515	Mount Flitch Plate
12	088001527	Flitch Bridge Weldment
13	844049002BG	Hex Lock Nut, 1/4-20 (Bag of 10)
14	088001579	Mounting Plate, 7-Pin Side
15	088001580	Mounting Plate, 10-Pin Side
16	088001544	Spacer, 5.0" Long
17	809849885BG	1/4-20 x5 1/2 Scr Hx Bg/10
17	809849885	Screw, Hex Hd, 1/4-20 X 5-1/2", Bag Of 10
18	809857125BG	Cap Screw, Hex Head, 5/16-18 X 0.75 (Bag of 10)
19	951156002BG	Spring (Split) Lock Washer 5/16 (Bag of 10)
20	947356617	Flat Washer 0.36 X 0.86 X 0.078 USS, Zinc Yellow Finish
21	088001829	Friction Plate
22	088001828	Friction Disc
23	088001820	Sheave Assembly
24	088001815	Shim Washer, .76 X 1.13 X.010
26	088001818	Washer, .76 X 1.50 X .072
27	088001528	Hex V-Belt, 35"
-	088001834	Spacer, EDGE Elevator Clutch
