QubicaAMF Pinspotter Parts 90 XLi Back End Cushion & Shock Absorber Assembly

Cushion & Shock Absorber Assembly

Позиция	Артикул	Наименование	Цена
№1	000022286	Collar Shock ABD Assembly	2 690 ₽
№2	000022287	Washer Spring Seat	1 460 ₽
№3	000022288	Spring Cushion Zinc Phosphate	2 090 ₽
№4	000022770	Pad Cushion Sponge, Rubber	7 360 ₽
№5	000022821	Special Pin (Custom)	400 ₽
№5	051200349	Clevis Pin 0.50 X 2.05	980 ₽
№6	000022822	Sleeve	460 ₽
№8	000022824	Shock Absorber Assembly	17 350 ₽
№9	000024534	Ear Hanger Cushion Assembly	630 ₽
№10	000024795	Plank, Left Hand	21 340 ₽
№11	000024796	Plank, Right Hand	21 340 ₽
№12	000024801BG	Flat Washer (Bag of 2)	1 530 ₽
№13	000024807	Cushion Rubber, Right Hand	24 280 ₽
№14	000024808	Cushion Rubber, Left Hand	24 280 ₽
№15	000026445	Pin Curtain, Right Hand and Left Hand	21 540 ₽
№15	000026450	Pin Curtain, Reversable	17 680 ₽
№16	V000028519-U	Super Rivet	0 ₽
№17	000028529	Cushion Rivets - Urethane "Plus" (Blue Urethane)	210 ₽
№18	070001389	Curtain Latch Spring	340 ₽
№19	070001396	Curtain Latch Pin	1 380 ₽
№20	070001421	Curtain Protection Pad (Strap)	290 ₽
№21	070001422	U Bolt, 5/16-18 X 4.25, Black Oxide Finish	370 ₽
№22	070001432	Curtain Protection Pad (Pad)	4 360 ₽
№23	070002050	Cusion tube Hanger Weldment, Odd Machine	24 780 ₽
№24	070002252	Cusion Tube Hanger Weldment, Even Machine	24 780 ₽
№25	070004738	Toe Guard	3 670 ₽
№26	070005610	Curtain Link	970 ₽
№27	070007360	Support bracket weldment	4 730 ₽
№28	612088506	Curtain Bushing Replacement Kit	1 600 ₽
№29	070011288	Curtain rod	3 160 ₽
№30	090005230	Cushion Facing	5 180 ₽
№30	090005279	CUSHION COVER, 6 HOLE	7 050 ₽
№31	808865320BG	Cap Screw, Flat Head, 3/8-16 X 2.00 Bg/10	1 030 ₽
№32	801865367BG	BG/5 Serrated Flange Bolt 2.25	1 630 ₽
№32	808865400BG	Cap Screw, Flat Head, Hex Socket Drive, 3/8-16 X 2.50 (Bag of 10)	1 740 ₽
№33	809849125	Cap Screw, Hex Head, 1/4-20 X 0.75	90 ₽
№34	809857125BG	Cap Screw, Hex Head, 5/16-18 X 0.75 (Bag of 10)	610 ₽
№35	809857165BG	Cap Screw, Hex Head, 5/16-18 X 1.00 (Bag of 10)	800 ₽
№36	809857205BG	Cap Screw, Hex Head, 5/16-18 X 1.25 (Bag of 10)	650 ₽
№37	810250200BG	Cap Screw, Socket Head, 1/4-20 X 1.25 (Bag of 10)	820 ₽
-	844057002BG	Curtain Protection Pad Hex Lock Nut, 5/16-18 (Bag of 10)	390 ₽
№39	844065002BG	Hex Lock Nut, 3/8-16 (Bag of 10)	530 ₽
№40	913431160BG	Spring Pin, 5/32 X 1 (Bag of 10)	710 ₽
№41	913437240BG	Spring Pin, 3/16 X 1-1/2 (Bag of 10)	670 ₽
№42	945091242	1 x 1 1/2 Washer	150 ₽
№43	948761112BG	Flat Washer 0.34 X 0.69 X 0.06 (Bag of 10)	270 ₽
№44	948975172BG	Flat Washer 1.06 X 0.53 X 0.09 (Bag of 10)	750 ₽
№45	951148002BG	Spring (Split) Lock Washer 1/4 (Bag of 10)	410 ₽
№46	951164002BG	Spring (Split) Lock Washer 3/8 (Bag of 10)	470 ₽
№47	963600002BG	X-Washer, 1/4", 9000-16 (Bag of 10)	970 ₽
-	612024000	Cushion Mount Hardware Kit	8 260 ₽
-	088000199	Cushion Asm, Odd	114 500 ₽
-	088000198	Cushion Assembly, Even	121 810 ₽
-	V000024795-6	Universal Cushion Plank	0 ₽
