QubicaAMF Запчасти пинсеттеров | Pinspotter Parts 8800 Horizontal Ball Return HBR (Horizontal Ball Return) Assembly

HBR (Horizontal Ball Return) Assembly

Позиция	Артикул	Наименование
1	090007023	Tube HBR Weldment
2	070001995	Upper Yoke Assembly
3	000024659	Yoke, Lower PBL
4	090007190	Pulley Horizontal Ball Return
5	090007191	V Guide Flat Belt
6	090007022	Roller Guide
7	090007003	Pulley, Horizontal Ball Return Driver
8	090006262	Tube
9	610900711	Straight Shaft and Spacer Kit - Upper
10	090007017	Shaft, Horizontal Ball Return Driver
11	090007021	Pin
13	090006263	Retainer
14	610905704	Straight Bore Bearing and Spacer Kit
15	000024650	Roller Assembly
16	070006748	Spacer, Ball Lift Shaft
17	809865445BG	Cap Screw, Hex Head, 3/8-16 X 2.75 (Bag of 10)
18	808865160	Screw SOFL 3/8-16 X 1
-	839665002BG	Hex Lock Nut, 3/8-16 (Bag of 10)
20	700107146	Adhesive, Loctite, Blue
21	710501007	Grease Fitting
22	856070002BG	Hex Flange Lock Nut, 7/16-20 (Bag of 10)
23	806265160BG	Set Screw, Square Head Cup Point, 3/8-16 X 1.00 (Bag of 10)
24	907300400	Woodruff Key, 605, 0.19 X 0.63
25	700107170	Loctite Adhesive RC609/10ML
26	000027642	Front Roller Flat Washer 0.76 X 1.25 X 0.05
27	715010307	Grease Lubrication
28	090007337	HBR Driven Asm
29	090007336	HBR Drive Asm
-	090007256	Bumper Rudder Arm
-	090007442	HBR Track End Support
