QubicaAMF Запчасти пинсеттеров | Pinspotter Parts 8290 - 90 XL Front End Bin & Shuttle Steel Bin Assembly

Steel Bin Assembly

Позиция	Артикул	Наименование
1	000021575	Insulator
2	000022168	Spring
3	000026043	Micro Switch
4	000026251BG	Roller Bearing, Threaded (Bag of 10)
5	000029614	Ball Bearing, Uniball
6	070006108	Spacer
8	000021992BG	Grommet, #2250 Bumper (Bag of 10)
9	070006351	Rod, Bin Assembly
10	070006353	Pin Guide
11	070006354BG	Bin Shock Mount Assembly (BAG 10)
12	070006356	Switch Actuator
13	070006358	Bracket Assembly
14	070006359	Bracket, Bin Assembly
15	070006360	Channel Weldment, Long
16	070006363	Channel, Short
17	070006364	Pin Butt Guide and Pin Head Guide (Butt Guide)
18	070006365	Spacer/Head Guide, Pins 2 and 3
19	070006366	Pin Butt Guide and Pin Head Guide (Head Guide)
20	070006369	Pin Guide, Right Hand (10 PS)
21	070006370	Pin Guide, Left Hand (7 PS)
22	070006371	Support Bracket
23	070006372	Stringer - Center Right Hand and Left Hand (10 Side)
24	070006373	Stringer - Center Right Hand and Left Hand (7 Side)
25	070006376	Stringer, Outside, Right Hand (10 PS)
26	070006377	Stringer, Outside, Left Hand (7 PS)
27	070006380	Pin Ear Guide (7 Side)
28	070006381	Pin Ear Guide (10 Side)
29	070006384	Bracket, #5 Pin Only
30	070006386	Track Assembly, Left Hand (7 PS)
31	070006388	Track Assembly, Right Hand (10 PS)
32	070006389	Pin Guide, #1 Pin
33	070006390	Spacer
34	070006402	Shaft, Bin Assembly
35	070006403	Clamp Stud
36	070006408	Lever Front End Asm
37	070006429	Arm Assembly
38	090005250	3/8 Rod End RH
39	701329050BG	Roller Bearing, Thrust, 0.89 X 1.50 X 0.13 (Bag of 10)
40	709013063	Cap Screw, Hex Head, M6 X 12mm
41	710501007	Grease Fitting
42	711516020	Push-In Grommet, 0.50 X 1.06 X 0.38
43	744107013	Clamp, Nylon, 1/8
44	785502207	Regular Type Flat Washer M6 DIN, Black Oxide Finish
45	809849085	Cap Screw, Hex Head, 1/4-20 X 0.50
46	809849285BG	Cap Screw, Hex Head, 1/4-20 X 1.75 (Bag of 10)
47	809849485BG	1/4-20 x 3 Scr HH Bg/10
47	809849485	Screw, Hex, 1/4 - 20 X 3
-	809865165BG	Cap Screw, Hex Head, 3/8-16 X 1.00 (Bag of 10)
49	809865205BG	Cap Screw, Hex Head, 3/8-16 X 1.25 (Bag of 10)
50	813540082BG	Screw, Pan Head, 10-32 X 0.50, Cadmium (Bag of 10)
51	818227082BG	Machine Screw, Pan Head, 6-32 X 0.50 Sems Bg/10
52	818227162BG	Machine Screw, Pan Head, 6-32 X 1.00 Sems Bg/10
53	831565002BG	Hex Finish Nut, 3/8-16, Cadmium (Bag of 10)
54	835566002	Hex Finish Jam Nut, 3/8-24
55	838670006	Hex Finish Nut, M6
56	843127002BG	Keps Nut, 6-32 (Bag of 10)
-	844049002BG	Hex Lock Nut, 1/4-20 (Bag of 10)
-	844065002BG	Hex Lock Nut, 3/8-16 (Bag of 10)
59	900114101BG	Bearing Sleeve, 0.88 X 1.13 X 0.63 (Bag of 5)
60	900206091BG	Flange Bushing, 0.38 X 0.50 X 0.56 (Bag of 5)
61	907000600BG	Hi-Pro Key, 706 (Bag of 10)
62	957100002BG	External Tooth Lock Washer #10, Shakeproof (Bag of 10)
-	809849125	Cap Screw, Hex Head, 1/4-20 X 0.75
64	808549080BG	Cap Screw, Button Head, 1/4-20 X 0.50 Bg/10
65	809849605BG	Cap Screw, Hex Head, 1/4-20 X 3.75 (Bag of 10)
