BRUSH - CLEANER PAD - TRANSFER ROLLER - VACUUM HEAD - VACUUM MOTOR - WASTE TANK
| Позиция | Артикул | Наименование |
|---|---|---|
| 1 |
01009
|
Machine Screw, Pan Head, 8-32 X 0.38 |
| 2 |
01016
|
#8 Ext Tooth Lockwasher |
| 4 |
01044
|
Cap Screw, Hex Head, 1/4-20 X 0.63, Grade 5, Zinc Finish |
| 5 |
01046
|
Cap Screw, Hex Head, 1/4-20 X 0.75, Grade 5, Zinc Finish |
| 6 |
01048
|
Cap Screw, Hex Head, 1/4-20 X 1.00, Grade 5, Zinc Finish |
| 7 |
838549002
|
Hex Finish Nut, 1/4-20 |
| 9 |
01159
|
Lock Nut, 7/16-20 |
| 10 |
02214
|
110V Vacuum Motor |
| 11 |
02255
|
220V Vacuum Motor |
| 12 |
03099
|
Buffer Drive Belt |
| 13 |
04120
|
2" I.D. STL. Clamp |
| 14 |
A0338
|
Upper VAC Motor Mount |
| 15 |
A0405
|
Lower Vac Motor Mount |
| 16 |
A0406
|
Vac Exhaust Plate |
| 17 |
A0952
|
Chain #25 14-3/4 Length |
| 18 |
A8307
|
Waste Tank Seal, 110v lane machines |
| 19 |
SA0256
|
Cleaner Pad Assembly |
| 20 |
SA0321
|
VAC-Head Slide BLock Mount Assembly |
| 21 |
SA0322
|
Cleaner Tray Mount Assembly, Right |
| 22 |
SA0323
|
Cleaner Tray Mount Assembly, Left |
| 23 |
SA1101
|
Vacuum Hose Assembly |
| 24 |
SA1105
|
Buffer Drive Assembly |
| 25 |
SA1106
|
Buffer Idler Assembly |
| 26 |
SA1129
|
Waste Tank Assembly |
| 28 |
SA1182
|
Oil Brush Tube Assembly |
| 29 |
SA9032
|
VAC-Head Assembly |
