Oil Tank Assembly
| Позиция | Артикул | Наименование |
|---|---|---|
| 1 |
294115084
|
Oil Tank Weldment |
| 2 |
04017
|
Flange Bushing, 0.38 X 0.50 X 0.38 |
| 3 |
B0661
|
Gemini Oil Tank Bar |
| 4 |
B0660
|
Gemini Oil Tank Angle |
| 5 |
294115160
|
Bracket |
| 6 |
01248
|
Machine Screw, Pan Head, 8-32 X 1.00 |
| 8 |
01423
|
Machine Screw, Pan Head, 10-32 X 1.25 |
| 9 |
04093
|
Viton Rubber Washer 0.76 X 0.58 X 0.06 |
| 10 |
A0330
|
Oil Tank Plug |
| 11 |
294115083
|
Oil Tank Mounting Bracket |
| 12 |
01351
|
Shoulder Bolt, Socket Head, Hex Socket Drive, 3/8 X 1.00 |
| 13 |
294115193
|
Sight Glass Tape |
| 14 |
294115189
|
Sight Glass Disk |
| 17 |
951632060
|
External Tooth Lock Washer #8 |
