One Piece Guide Tower Assembly
Позиции с кодом N.A.:
- 6 — N.A. — Tension Screw
- 33 — *N.A. — Guide Beam
| Позиция | Артикул | Наименование |
|---|---|---|
| 1 |
11-051856-001
|
Retaining Ring |
| 2 |
11-053497-000
|
Key |
| 3 |
11-430052-000
|
Bearing |
| 4 |
47-071589-003
|
Jam Lever |
| 5 |
11-051703-001
|
Hex Nut |
| 7 |
47-071591-004
|
Sprocket Shaft |
| 8 |
55-050635-004
|
Tension Spring |
| 9 |
11-601007-000
|
Roller Chain (64 Links) |
| 10 |
47-011053-004
|
Sprocket |
| 11 |
11-051852-001
|
Retaining Ring |
| 12 |
11-051741-001
|
Locknut |
| 13 |
11-052025-001
|
Flat Washer |
| 14 |
11-052207-001
|
Slotted Machine Screw |
| 14 |
47-861015-001
|
Slotted Machine Screw |
| 15 |
99-050229-004
|
Switch (Red Box only) |
| 16 |
11-051005-001
|
Hex Hd. Cap Screw |
| 17 |
47-071975-004
|
Threaded Connector |
| 18 |
11-051706-001
|
Hex Nut |
| 19 |
11-052024-001
|
Flat Washer |
| 19 |
47-861010-001
|
Flat Washer |
| 20 |
11-052052-001
|
Flat Washer |
| 21 |
11-051772-001
|
Lockwasher |
| 22 |
11-051057-001
|
Hex Hd. Cap Screw |
| 23 |
11-051009-001
|
Hex Hd. Cap Screw |
| 24 |
11-052053-001
|
Flat Washer |
| 24 |
47-861011-001
|
Flat Washer |
| 25 |
47-071341-003
|
Crank Arm |
| 26 |
47-071342-003
|
Crank |
| 27 |
11-053495-000
|
Key |
| 28 |
11-052206-001
|
Slotted Machine Screw |
| 29 |
11-051786-001
|
Cotter Pin |
| 30 |
11-051745-001
|
Locknut |
| 31 |
11-600500-000
|
Master Link (3 pieces) |
| 32 |
99-050230-004
|
Switch (red box) |
| 34 |
47-071343-004
|
Clevice |
| 35 |
47-243026-004
|
Switch (silver box, consolidated and nexgen) |
| 36 |
47-243027-004
|
Switch Complete (silver, consolidated and nexgen electronics box) |
