Left Drive Frame Assembly
Позиции с кодом N.A.:
- 27 — N.A. — Pop Rivet
| Позиция | Артикул | Фото | Наименование | Цена | |
|---|---|---|---|---|---|
| - |
47-073795-004
|
Cable Channel |
0 ₽ | ||
| - |
47-071779-001
|
Gear Train Frame (left-hand) |
0 ₽ | ||
| - |
11-051744-001
|
Locknut |
0 ₽ | ||
| - |
11-051005-001
|
Hex Hd. Cap Screw |
0 ₽ | ||
| - |
47-070186-003
|
Sweep Shaft Support |
0 ₽ | ||
| - |
11-051038-001
|
Hex Hd. Cap Screw |
0 ₽ | ||
| - |
11-051010-001
|
Hex Hd. Cap Screw |
0 ₽ | ||
| - |
47-073832-004
|
Shaft Bearing Assembly w/Cut Retainer Plate |
0 ₽ | ||
| - |
47-081958-004
|
Sweep Bearing Holder |
0 ₽ | ||
| - |
47-223077-004
|
Frame Counter Assembly |
0 ₽ | ||
| - |
11-051011-001
|
Hex Hd. Cap Screw |
0 ₽ | ||
| - |
11-051770-001
|
Lockwasher |
0 ₽ | ||
| - |
11-052901-000
|
Bearing Assembly w/Retaining Plates |
0 ₽ | ||
| - |
11-051704-001
|
Hex Nut |
0 ₽ | ||
| - |
11-051703-001
|
Hex Nut |
0 ₽ | ||
| - |
11-051771-001
|
Lockwasher |
0 ₽ | ||
| - |
47-070169-004
|
Angle Bracket |
0 ₽ | ||
| - |
11-051046-001
|
Hex Hd. Machine Screw |
0 ₽ | ||
| - |
11-052902-000
|
Shaft Bearing Assembly w/Retaining Plates |
0 ₽ | ||
| - |
11-052003-001
|
Flat Washer |
0 ₽ | ||
| - |
99-010107-004
|
Bushing |
0 ₽ | ||
| - |
11-053619-001
|
Stop Collar |
0 ₽ | ||
| - |
11-052803-001
|
Set Screw |
0 ₽ | ||
| - |
47-040283-003
|
Sweep Guide Lever |
0 ₽ | ||
| - |
11-051794-001
|
Cotter Pin |
0 ₽ | ||
| - |
11-052024-001
|
Flat Washer |
0 ₽ | ||
| - |
47-861010-001
|
Flat Washer |
0 ₽ | ||
| - |
47-081959-003
|
Sweep Shaft Bearing |
0 ₽ | ||
| - |
47-041530-002
|
Sweep Shaft |
0 ₽ | ||
| - |
47-052123-004
|
Spring Shaft |
0 ₽ | ||
| - |
47-052120-004
|
Tension Spring |
0 ₽ | ||
| - |
47-073797-004
|
Cable Channel |
0 ₽ |
